TC2000 Multi Parameter Intelligent Controller
Application Areas:
• Wastewater
• Drinking water
• Industrial water
• Miscellaneous
Key words:
Classification:
- 产品描述
- Product Features
- Performance Index
- Field Application
-
Application industry• Wastewater• Drinking water• Industrial water• Miscellaneous -
High Scalability
- Supports 8 channels for independent connection of up to 19 types of sensors, featuring high integration and modular design for flexible configuration.
- Compatible with multiple communication protocols, including DP, HART, and MQTT.
High Reliability
- Platform-based design ensures robust stability, with an IP67 protection rating for direct outdoor installation.
- Equipped with pre-diagnostic and pre-maintenance functions to effectively reduce downtime risks.
Rich Functionality
- Supports 4G/WIFI wireless networking, eliminating wiring challenges.
- Real-time data curve display facilitates process debugging and daily inspections.
- Comprehensive data and information recording enhances equipment management efficiency.
- Guided interactive design ensures simple and intuitive operation.
"Tomorrow-Ready" Features
- Features a 7-inch high-brightness touchscreen, delivering a "smartphone-like" user experience.
- Seamless cloud connectivity enables smart interconnection of multiple devices.
- Access data anytime, anywhere via a "mini-program."
- Supports OTA remote firmware upgrades for continuous optimization.
Supported Sensor Categories
Dissolved Oxygen Sensor
Suspended Solids (Sludge) Concentration Sensor
Turbidity/Suspended Solids Concentration Sensor
pH/ORP Analog Electrode
Digital pH Sensor
Digital ORP Sensor
Conductivity Analog Electrode
Digital Conductivity Sensor
UVCOD Sensor
Electrode-based Ammonia Nitrogen Sensor
UV-based Nitrate Nitrogen Sensor
Spectral Water Quality Sensor
Free Chlorine Sensor
...
-
Technical Specifications
Details
Display screen
7-inch capacitive color touch screen
Dimensions (W x H x D)
240*195*175mm
Enclosure
ABS+PC housing
Weight
1.8kg (controller only, without sensor module)
Ingress protection
IP67
Power supply
Communication controller: 100~240 VAC ± 10%, 50/60 Hz;
DC controller: 18~36 VDC, maximum 25WOperating temperature
-20~60 °C, under maximum effect: -20~55°C
Storage temperature
-40~70℃
Relative humidity
10~95%, no condensation
Sensors are supported
Digital sensors, analog sensors
Relays
3-way relay (SPST), support extension 9-way
Analog output
2 channels of 0/4~20 mA signal, support extension of 8 channels
Numeric communication
RS485, Supports Modbus RTU protocol, optional: Profibus DP, HART
Network connection
4G network, expandable: LAN Ethernet connector, wifi function
USB port
For data downloads and software upgrades
Data storage
Built-in 32G data memory card, storing more than 10 years of data
